    World's Smallest Electric Strike!

    SKU: TR3234-12V-26D

    Trine



    For use with metal door frames.

    Finish
    Voltage

    Quantity left : 0

    Shield

    EXTENDED PROTECTION PLAN

    3 Years of SHIELD Coverage

    Product Replacement | Extended Return Policy | Price Protection

    Terms and Conditions

    $28.00

    Call For Price
    • Stainless steel construction
    • Use on metal door frames – have a wood frame?  Simply order the 3334W
    • Compact design electric door strike with built-in face-plate
    • Tested for 500,000 cycles
    • Fail-secure – stays locked should power be interrupted
    • Standard operating voltages of 12VDC or 24VDC – power supplies available at checkout
    • 1″ total backset, accepts latchbolts with up to 5/8″ throw
    • 1-year manufacturer warranty

    They said it couldn't be done.  They said it was not possible.  Well, the truth is Trine Access Technology has made it a reality.  Meet what is dubbed the world's smallest electric door strike.  With up to 70% less cutting of the frame during installation, the Trine 3000 series has rapidly become the go-to strike for completing a door release or access control system.  Install this in place of a standard door strike when you are using an outside keypad, prox card reader, or fingerprint reader or when you are wanting to remotely release the door from inside your home or building; for example, you have an intercom system, or you want your secretary to be able to buzz people in.

    Basic

    Manufacturer Trine
    Holding Force 1200lb
    Warranty 1 Year Manufacturer
    Brand Trine

    Door requirements

    Security

    Dimensions

    Dimensions Face-plate: 2 3/4 x 1 1/8 in., Interior: 11/32 (W) x 1 11/16 (H) x 7/8 (D) in.
