Securitron DK-12

• Stainless steel backplate with 12 keys (10 digits plus "*" and "#" keys)
• One piece digital keypad specifically designed for control of electric locks including electric door strikes and maglocks
• Single gang, stainless steel plate with plastic backbox
• Includes 4 user code capability which is programmable from the keypad
• 5 Amp SPDT timed, control relay output
• Two LEDs are furnished
• Both LEDs also provide programming prompt
• Red and Green LEDs are visible indicators
• Optional weather cover available at checkout
• Request to Exit (REX) input
• Wiegand output available

Specs

• Current Draw: 70mA
• Voltage: 12 or 24VDC (power supplies available at checkout)
• Operating Temperature: +32 to +110F
• Warranty: MagnaCare Lifetime Replacement Warranty

The DK-12 (replaces DK-11) is a one piece unit designed for lower security requirements. While primarily intended for indoor operation, an optional rain cover (WCC) and gasketed backbox (WBB) allow reliable use for exterior areas not exposed directly to rain or snow.
