Accommodates interior, exterior, metal, and non-metal installation environments
Two-factor Authentication with anti-bacterial keypad
Recognizes most proximity credentials, and Schlage smart credentials (MIFARE classic and MIFARE DESFire EV1)
Reads CSN (card serial numbers) of HID iCLASS, Inside Technologies PicoTag, ST Microelectronics, Texas Instruments Tag-It, and Phillips I-Code
FIPS 201-1 Compliant
NFC Compatible
Quick-connect design for easy installation
Simple wiring – color scheme is identical to most readers in the market
Easy-to-install mounting bracket
Tri-state LED (red, green, amber) visual indicator and audio feedback representing status and activity information, easily discernible for the audibly or visually impaired.
Rounded corners, flush fit to wall
Wiegand output for simple interface with most access control panels
Standard color is black. Multiple reader cover color options including gray, brown, and cream may be specially ordered
Limited Lifetime Warranty
Multi-technology readers may also be specially ordered with RS-485 capability
The MTK15 reader is a replacement for (S)XF2110, (S)XF2110P-K, and (S)XF2210 legacy reader products.
Specs
Physical Dimensions (HWD): 5.1″ x 3.25″ x 0.76″
Frequency: 13.56 MHz and 125 kHz
Standard Default PIV Output: 75 bit†
Standards: ISO 14443A, 14443B, 15693
Power: 5-16 VDC
Wiring: 18 or 20 AWG 12 shielded wire, depending on distance to panel
Read Range: Proximity: Up to 5” (12.7 cm), MIFARE: Up to 4” (10 cm), DESFire EV1: Up to 2” (5.1 cm), PIV Credential: Up to 2.5” (6.5 cm)
Operating Temperatures: -40 to 158F (-40 to 70C)
Material: PBT Polymer
† Configurable to other output formats. Check with access control provider for specific support.
Edgy, easier for installers to work with, and built to help you keep up with new technologies, the Schlage MTK15 multi-technology reader has garnered a ton of buzz since its unveiling. With an open architecture design, Schlage readers can be integrated into any existing access control system. This means a one size fits all solution for handling your current proximity needs today, and preparing you for smart technology in the future, along with the next step up, NFC technology, where phones will be used as credentials. With this much functionality in one reader, you will save time, and avoid the tension, and gargantuan costs that can come with having to switch all readers over at once. Schlage lets you make a gradual changeover to the new technologies at a pace that is comfortable for you. The MTK15 supports multi-factor authentication for access into high risk areas, or spaces with high valued assets, for example at a financial institution. In this tightly controlled environment, users will be required to not only possess their card, but must also know the PIN to be permitted access.
Basic
Manufacturer
XceedID Corporation
Reader Type
Front-end Only Multi-Technology + Keypad Prox Card/Fob Smart Card
